LUNA Downlight 3x1W / LED Puck Kit
LUNA Downlight 3x1W / LED Puck Kit
The LUNA LED downlight adopts 3 pcs original CREE XPE LEDs as the light source, and is manufactured with frosted PMMA lens. The beam angle can be 25°, 40°, and 60°. For installation convenience, each LUNA LED downlight is provided with a piece of 2.5 Meter wire connector to connect with power supply.
Specifications for EACH SIGNLE LAMP
Light Source: 3 pcs original CREE XPE LEDs
Lens material: Frosted PMMA lens
Lamp Service Life: 30,000 hours
Beam Angle: 25° / 40° / 60° Optional
Housing: Aluminum, silver surface
PCB Material: Aluminum PCB
Certification: CE, RoHS
Input voltage: 12VAC/DC , 50~60 Hz
Current: 247mA(Cool White) , 273mA(Warm White)
Dimmability: Not dimmable
Accessories: Each lamp is with a piece of 2.5 Meter wire connector to connect with power supply
| Part No. | Dimension (MM) | Lumen | LED type / Qty | CCT (K) | CRI | Power | Input |
| DL-P3W3-3S-DX-C-** | Dia 68 x Height 16.5 | 234 lm | CREE XPE R2 / 3 | 6500K | 72 | 3W | 12V DC/AC |
| DL-P3W6-3S-DX-C-** | Dia 68 x Height 16.5 | 202 lm | CREE XPE Q3 / 3 | 3000K | 80 | 3W | 12V DC/AC |
1) "**" for beam angle of the product, B=25°; E=40°; G=60°
