Tuerca de retención NL NS
Solicite un presupuesto
Uso: para utilizarlo con mangueras hidráulicas trenzadas
Materiales:- Tuerca de retención de acero inoxidable
- Tuerca de retención de acero al carbono
| Pieza Nº | Type | Rosca (E) | Diámetro externo del tubo | Dimensiones | |||
| C | d | S2 | |||||
| NL-12 | Light duty type retaining nuts | M12×1.5 | 6 | 14.5 | 6 | 14 | |
| NL-14 | M14×1.5 | 8 | 14.5 | 8 | 17 | ||
| NL-16 | M16×1.5 | 10 | 15.5 | 10 | 19 | ||
| NL-18 | M18×1.5 | 12 | 15.5 | 12 | 22 | ||
| NL-22 | M22×1.5 | 15 | 17 | 15 | 27 | ||
| NL-26 | M26×1.5 | 18 | 18 | 18 | 32 | ||
| NL-30 | M30×2 | 22 | 20 | 22 | 36 | ||
| NL-30D | M30×1.5 | 22 | 20 | 22 | 36 | ||
| NL-36 | M36×2 | 28 | 21 | 28 | 41 | ||
| NL-36D | M36×1.5 | 28 | 21 | 28 | 41 | ||
| NL-45 | M45×2 | 35 | 24 | 35 | 50 | ||
| NL-45D | M45×1.5 | 35 | 25 | 35 | 50 | ||
| NL-52 | M52×2 | 42 | 24 | 42 | 60 | ||
| NS-14 | Heavy duty type retaining nuts | M14×1.5 | 6 | 16.5 | 6 | 17 | |
| NS-16 | M16×1.5 | 8 | 16.5 | 8 | 19 | ||
| NS-18 | M18×1.5 | 10 | 17.5 | 10 | 22 | ||
| NS-20 | M20×1.5 | 12 | 17.5 | 12 | 24 | ||
| NS-22 | M22×1.5 | 14 | 20.5 | 14 | 27 | ||
| NS-24 | M24×1.5 | 16 | 20.5 | 16 | 30 | ||
| NS-30 | M30×2 | 20 | 24 | 20 | 36 | ||
| NS-36 | M36×2 | 25 | 27 | 25 | 46 | ||
| NS-42 | M42×2 | 30 | 29 | 30 | 50 | ||
| NS-52 | M52×2 | 38 | 32.5 | 38 | 60 | ||
