Conexión con Inserto PEX, para EUA HS240
Solicite un presupuesto
Accesorios para tubos PEX
Características
- Apropiado para el sistema de fontanería
- Opciones de rosca: Rosca macho NPT, rosca hembra NPSM
- De acuerdo a las normas ANSI/ASME B1.20.1 y F1807
- Opciones de material: Latón C46500
Tamaño | Dimensión nominal y tolerancia | ||||
A(mm) | B(mm) | C(mm) | |||
3/8" | Ф8.76 | ±0.1 | 5.85 | 0.1 | MIN16.0 |
1/2" | Ф11.96 | ±0.1 | 8.89 | 0.1 | MIN16.0 |
5/8" | Ф14.48 | ±0.1 | 11.46 | 0.1 | MIN16.0 |
3/4" | Ф16.94 | ±0.1 | 13.47 | 0.1 | MIN16.0 |
1" | Ф21.74 | ±0.1 | 18.04 | 0.1 | MIN20.5 |
1 1/4" | Ф26.54 | ±0.1 | 22.1 | 0.1 | MIN24.0 |
1 1/2" | Ф31.32 | ±0.15 | 25.91 | 0.15 | MIN29.0 |
2" | Ф40.69 | ±0.15 | 34.68 | 0.15 | MIN38.0 |
Estructura
- Acoplamiento recto
- Racor en codo
- Racor en T
Acoplamiento recto
Acoplamiento simétrico y acoplamiento reductor, HS240-001
TAMAÑO | ||
3/8“×3/8“ | 1/2“×3/8“ | 1 1/2“×1 1/4“ |
1/2“×1/2“ | 3/4“×1/2“ | 2“×1“ |
5/8“×5/8“ | 3/4“×5/8“ | 2“×1 1/4“ |
3/4“×3/4“ | 1“×3/4“ | 2“×1 1/2“ |
1“×1“ | 1 1/4“×3/4“ | |
1 1/4“×1 1/4“ | 1 1/4“×1“ | |
1 1/2“×1 1/2“ | 1 1/2“×3/4“ | |
2“×2“ | 1 1/2“×1“ |
Adaptador hembra roscado , HS240-002
TAMAÑO | ||
3/8“×1/2"F | 3/4“×3/4"F | 1 1/2“×1 1/2"F |
1/2“×1/2"F | 3/4“×1"F | 2“×2"F |
1/2“×3/4"F | 1“×3/4"F | |
5/8“×1/2"F | 1“×1"F | |
5/8“×3/4"F | 1 1/4“×1"F | |
3/4“×1/2"F | 1 1/4“×1 1/4"F |
Adapatdor macho roscado, HS240-003
TAMAÑO | ||
3/8“×1/2"M | 3/4“×3/4"M | 1 1/2“×1 1/2"M |
1/2“×1/2"M | 3/4“×1"M | 2“×2"M |
1/2“×3/4"M | 1“×3/4"M | |
5/8“×1/2"M | 1“×1"M | |
5/8“×3/4"M | 1 1/4“×1"M | |
3/4“×1/2"M | 1 1/4“×1 1/4"M |
Adaptador hembra de purga HS240-004
TAMAÑO | ||
3/8“×1/2"F | 3/4“×3/4"F | 1 1/2“×1 1/2"F |
1/2“×1/2"F | 3/4“×1"F | 2“×2"F |
1/2“×3/4"F | 1“×3/4"F | |
5/8“×1/2"F | 1“×1"F | |
5/8“×3/4"F | 1 1/4“×1"F | |
3/4“×1/2"F | 1 1/4“×1 1/4"F |
Adaptador macho de purga, HS240-005
TAMAÑO | ||
3/8“×1/2"M | 3/4“×3/4"M | 1 1/2“×1 1/2"M |
1/2“×1/2"M | 3/4“×1"M | 2“×2"M |
1/2“×3/4"M | 1“×3/4"M | |
5/8“×1/2"M | 1“×1"M | |
5/8“×3/4"M | 1 1/4“×1"M | |
3/4“×1/2"M | 1 1/4“×1 1/4"M |
Adaptador giratorio con tuerca de latón, HS240-013
TAMAÑO |
3/8“×3/8"F |
3/8“×1/2"F |
1/2“×1/2"F |
1/2“×3/4"F |
3/4“×3/4"F |
3/4“×1"F |
1“×1"F |
Adaptador giratorio con tuerca de plástico, HS240-014
TAMAÑO |
3/8“×3/8"F |
3/8“×1/2"F |
1/2“×1/2"F |
1/2“×3/4"F |
3/4“×3/4"F |
3/4“×1"F |
1“×1"F |
Tapón de latón, HS240-016
TAMAÑO |
3/8“ |
1/2“ |
5/8“ |
3/4“ |
1“ |
1 1/4“ |
1 1/2“ |
2“ |
Adaptador de polibutileno con anillo de fijación PB, HS240-017
TAMAÑO |
3/8“ |
1/2“ |
3/4“ |
Codo
Codo y codo reductor, HS240-006
TAMAÑO | |
3/8“×3/8“ | 1/2“×3/8“ |
1/2“×1/2“ | 3/4“×1/2“ |
5/8“×5/8“ | 3/4“×5/8“ |
3/4“×3/4“ | 1“×3/4“ |
1“×1“ | |
1 1/4“×1 1/4“ | |
1 1/2“×1 1/2“ | |
2“×2“ |
Codo hembra roscado, HS240-007
TAMAÑO | ||
3/8“×1/2"F | 3/4“×3/4"F | 1 1/2“×1 1/2"F |
1/2“×1/2"F | 3/4“×1"F | 2“×2"F |
1/2“×3/4"F | 1“×3/4"F | |
5/8“×1/2"F | 1“×1"F | |
5/8“×3/4"F | 1 1/4“×1"F | |
3/4“×1/2"F | 1 1/4“×1 1/4"F |
Codo macho roscado, HS240-008
TAMAÑO | ||
3/8“×1/2"M | 3/4“×3/4"M | 1 1/2“×1 1/2"M |
1/2“×1/2"M | 3/4“×1"M | 2“×2"M |
1/2“×3/4"M | 1“×3/4"M | |
5/8“×1/2"M | 1“×1"M | |
5/8“×3/4"M | 1 1/4“×1"M | |
3/4“×1/2"M | 1 1/4“×1 1/4"M |
Codo hembra de purga, HS240-009
TAMAÑO |
3/8“×1/2"F |
1/2“×1/2"F |
1/2“×3/4"F |
5/8“×3/4"F |
3/4“×1/2"F |
3/4“×3/4"F |
1“×1"F |
Codo macho de purga, HS240-010
TAMAÑO |
1/2“×1/2"M |
1/2“×3/4"M |
5/8“×3/4"M |
3/4“×3/4"M |
1“×1"M |
Codo con placa de pared, HS240-011
TAMAÑO |
3/8“×1/2"F |
1/2“×3/8"F |
1/2“×1/2"F |
3/4“×1/2"F |
3/4“×3/4"F |
Codo giratorio con tuerca de plástico, HS240-015
TAMAÑO |
3/8“×3/8"F |
3/8“×1/2"F |
1/2“×1/2"F |
1/2“×3/4"F |
3/4“×3/4"F |
Unión en T
T y T de reducción, HS240-012
TAMAÑO | ||||
3/8“×3/8“×3/8“ | 1/2“×1/2“×3/8“ | 1“×3/4“×1/2“ | 1 1/2“×1 1/4“×3/4“ | 2“×1 1/2“×1 1/2“ |
1/2“×1/2“×1/2“ | 1/2“×1/2“×3/4“ | 1“×1/2“×3/4“ | 1 1/2“×1 1/4“×1“ | 2“×2“×1/2“ |
5/8“×5/8“×5/8“ | 3/4“×3/4“×3/8“ | 1“×1/2“×1“ | 1 1/2“×1 1/4“×1 1/4“ | 2“×2“×3/4“ |
3/4“×3/4“×3/4“ | 3/4“×1/2“×1/2“ | 1 1/4“×1“×3/4“ | 1 1/2“×1 1/2“×1/2“ | 2“×2“×1“ |
1“×1“×1“ | 3/4“×1/2“×3/4“ | 1 1/4“×1“×1“ | 1 1/2“×1 1/2“×3/4“ | 2“×2“×1 1/4“ |
1 1/4“×1 1/4“×1 1/4“ | 3/4“×3/4“×1/2“ | 1 1/4“×1 1/4“×1/2“ | 1 1/2“×1 1/2“×1“ | 2“×2“×1 1/2“ |
1 1/2“×1 1/2“×1 1/2“ | 3/4“×3/4“×1“ | 1 1/4“×1 1/4“×3/4“ | 1 1/2“×1 1/2“×1 1/4“ | |
2“×2“×2“ | 1“×3/4“×1“ | 1 1/4“×1 1/4“×1“ | 2“×1 1/4“×1 1/4“ | |
3/8“×3/8“×1/2“ | 1“×1“×1/2“ | 1 1/2“×3/4“×3/4“ | 2“×1 1/2“×3/4“ | |
1/2“×3/8“×3/8“ | 1“×1“×3/4“ | 1 1/2“×1“×3/4“ | 2“×1 1/2“×1“ | |
1/2“×3/8“×1/2“ | 1“×3/4“×3/4“ | 1 1/2“×1“×1“ | 2“×1 1/2“×1 1/4“ |
